9.03.03 List of parameters for control unit P45 PD2-L
Only appropriately trained personnel is authorized to alter the set values in the
parameters of user level "B" and "C".
Group Parameter Description User level Setting range Set value
1
105 Speed at seam start B 300 - 2000 800
110 Speed at seam end B 300 - 2000 800
111 Light barrier compensating stitches A 1 - 30 8
112 No. of stitches for blocking out light barrier
for knitted fabrics
A 0 - 100 0
113 Start with light barrier
ON = only if light barrier dark
OFF = also when light barrier bright
B ON - OFF OFF
116 Soft starting stitches (soft start) A 0 - 30 0
117 Speed for soft starting stitches (soft start) B 120 - 1000 400
189 Drive runtime in life test in 0.1sec C 10 - 600 50
190 Drive stop time in life test in 0.1sec C 10 - 600 50
199 Speed for light barrier compensating
stitches
B 300 - 2000 1200
2
206 Interrupt /stop seam section at fi xed speed
ON = with pedal -2,
OFF = with pedal 0
B ON - OFF OFF
219 Poti for stroke adjustment
ON = activated, OFF = off
B ON - OFF ON
402 Speed at max. stroke adjustment B 300 - 6400 1000
4
422 Output
1 = wiper
2 = thread clamp
3 = motor operation
B 0 - 3 2
438 Output is
ON = motor operation
OFF = trimming
B ON - OFF ON
