Sewing
18
8 Sewing
In the sewing mode all settings, which are relevant for the sewing operation, are shown on
the display. Functions can be switched on or off by pressing a key, set values for the most
important parameters can be altered directly.
The "PM" selection key is used to choose between manual sewing (LED in the selection key
is off) and programmed sewing (LED in the selection key is on).
8.01 Manual sewing
● Switch on the machine.
● Select manual sewing (LED in the selection key is off) by pressing the "PM" key.
● By pressing the "scroll" key it is possible to choose one of the following display diagrams:
Start and end tacks
3 3 3 3
111a 8
Parameters
3000
Speed
When the machine is switched on, the display diagram, which was activated
before the machine was switched off, always appears.
