Performing an Exam Ending an Exam
100 Lumify Ultrasound System
Philips Healthcare 4535 618 58571_A/795 * MAY 2016
1. Obtain the image you want to annotate and touch .
2. If necessary, touch the page indicator ( or ) or swipe to display Annotate .
3. Touch Annotate .
4. Use the keyboard to type a label. Auto-words appear to the left and right of the letters you
are typing. You can touch an auto-word to add it to your label.
5. Drag the label into position in the imaging area.
6. To edit a label:
a. Touch the label. A line and the keyboard appear beneath it.
b. Touch a starting point in the label and begin typing, or use the Backspace key to erase
letters.
c. Touch anywhere in the imaging area to exit annotation.
7. To delete a label, touch and hold the label. Touch Delete Annotation when it appears.
Ending an Exam
WARNING
Failing to end the current exam before starting a new exam can result in data being acquired
and stored under the wrong patient name. If you turn off the system without ending the
exam, the system pauses the exam before shutting down.
Each time you finish an exam, you must end the exam to save images and other exam data. You
cannot end an exam while in Review.
