Performing an Exam Performing a 2D Distance Measurement
96 Lumify Ultrasound System
Philips Healthcare 4535 618 58571_A/795 * MAY 2016
NOTE
If you spread or pinch inside a color box, you resize the color box instead of zooming.
Full-Screen View
You can specify that Lumify display live or frozen images in full-screen view, including in
Review.
1. To view an image in full-screen view, touch in the lower right corner of the image.
2. To restore normal viewing, touch .
Displaying a Centerline
You can display a centerline during live imaging (including when an image is frozen) to assist
with needle guidance. The line is included in acquired images or loops.
To display the centerline, touch on the lower left corner of the imaging display. To hide the
centerline, touch again.
Performing a 2D Distance Measurement
A 2D distance measurement uses two calipers to measure the length of a straight line between
the two points.
You cannot zoom an image while you are using the 2D distance measurement tool. The system
removes measurements from the image when it is unfrozen or when the exam ends. To retain
the measurement on an image, acquire it (see “Acquiring Images” on page 98).
