Using the System Imaging Display
80 Lumify Ultrasound System
Philips Healthcare 4535 618 58571_A/795 * MAY 2016
Imaging Display (Landscape Orientation)
A Controls area
B Image area
C Patient information
1 Scan plane orientation marker
2 MI and TI values
3 Focal indicator
4 Page indicator: Touch the indicator to go to the next page of controls, or swipe to move between pages.
5 Image information
6 Review and settings menu
