General Recorder Information
6-2 Recording Functions
Recording Functions
General Recorder Information
Recorders The following recorders are available for use with the patient monitors:
The Plug-In recorder has 2 channels, and can also be used at a central
location.
The 4-channel thermal recorder can also be used at a central location.
The Philips central recorder records the waves you select for
transmission over the Philips patient care system.
This document provides configuration information for the Plug-In, 4-
channel, and central recorders. The controls and indicators on the Plug-
In and 4-channel are also described.
For information about the 2-channel bedside and the central recorder
controls, please refer to the relevant operating guide.
Recorder
Model Number
Plug-In M1116A/B
a
a. Only the M1116B can be used with the Philips Information Center
4-Channel Bedside M1117A (CMS only)
2-Channel Bedside 78574A (CMS only)
