Making Changes to the Main Display
Setting up your Monitor 3-7
Setting up your
Monitor
Making Changes to the Main Display
The following describes how to change screen A, B, C, D, or E and assign
a label. The description includes:
• Assigning Waves to Screen Channels
• Selecting a Screen
• Selecting Screen Labels for Realtime Display Screens
• Selecting the Number of Waves
• Selecting the Wave Overlap Configuration
• Selecting Realtime Wave Speeds
• Numerics On/Off
• Selecting an Application Window
• Wave Replace Mode
•Trace Mode
A description is then given for changing a completely separate display
screen.
