Assigning Waves to Screen Channels
Setting up your Monitor 3-9
Setting up your
Monitor
Procedure 1. Press repeatedly to select a channel on the
screen.
2. Press to move the selection to the wave you want
to place in your selected channel.
3. Repeat steps 1 and 2 for each wave position you want to change.
4. Press to return to the Main Screen screen.
Note—If one of the assigned waves is not available (parameter switched
off or unplugged), then another wave will use its channel until the
assigned wave is reactivated, provided Wave Replace Mode is enabled.
The channel will only remain blank if:
• It is assigned to ECG or Blank.
• Another wave is available, but numerics aligned to that wave are
switched off.
Main Screen
To Next Page
