Selecting Screen Labels for Realtime Display Screens
3-12 Setting up your Monitor
Setting up your
Monitor
h. Inductn
i. Non Invasive
j. OxyCRG3.
k. Blank (No screen label).
l. User Def (user defined screen label - see below)
3. Press to return to the Selection Window or press
to return to the Main Screen screen.
User Defined
Screen Labels
In addition to the pre-defined screen labels, you can define your own
labels for each screen (A-E). To define a screen label:
1. Select User Def in the Display Setup Task Window.
2. Press .
3. Enter new label using either the handheld keypad, the touchboard
(CMS only) or the arrow keys (V24 and V26).
4. Press .
5. The user defined labels will also appear in the Change Screen Task
Window
Monitor Setup
Main Screen
Confirm
Confirm
To Next Page
