FL MGUARD GT/GT
168
PHOENIX CONTACT 105656_en_05
8.1.2 Messages in the 7-segment display
During error-free operation:
Messages during operation with the memory module:
Messages in Smart mode:
For Smart Mode, see “Restart, recovery procedure, and flashing the firmware” on page 186
Display Meaning
bo Extracting/starting firmware (boot)
01 The device is in normal operating mode and tries to obtain network pa-
rameters from a BootP/DHCP server using DHCP requests
03 Downloading firmware via TFTP
04 Loading firmware in the Flash memory that was loaded via the network
05 The recently loaded firmware was successfully saved in the Flash mem-
ory
06 New firmware was successfully saved in the Flash memory, a rollout
script was downloaded via TFTP and executed
08 The device is in Rescue mode and tries to obtain network parameters
from a BootP/DHCP server using DHCP requests in order to request a
firmware image
_ _ _ Initializing firmware
- - - Firmware running in normal mode
rB Device rebooting
0r Recovery procedure is deactivated according to the installed customized
default profile
0d Customized default profile cannot be applied (e.g., it is not installed)
Display Meaning
5c Save configuration data on the MEM PLUG
EC Equal configuration - the configurations on the MEM PLUG and the de-
vice are the same
dC Different configuration - the configurations on the MEM PLUG and the de-
vice are different
0C The MEM PLUG is empty
FC Not enough memory on the memory module to save the configuration
HC This MEM PLUG is not compatible with the device, e.g., a wireless ID
plug or an MRP master
Display Meaning
51 Smart mode “No changes”
55 Smart mode “Recovery procedure”
56 Smart mode “Flash procedure”
57 Smart mode “Customized default profile”
