TC MGUARD RS4000/RS2000 4G
105656_en_05 PHOENIX CONTACT 79
Info2 Green On Up to firmware version 8.0 As of firmware version 8.1
The configured VPN connection has
been established at output O1.
The configured VPN connections are
established at output O1 or the firewall
rule records defined at output O1 are
activated.
Flashing The configured VPN connection is
being established or aborted at output
O1.
The configured VPN connections are
being established or aborted at output
O1 or the firewall rule records defined at
output O1 are activated or deactivated.
Info1 Green On Up to firmware version 8.0 As of firmware version 8.1
The configured VPN connection has
been established at output O2.
The configured VPN connections are
established at output O2 or the firewall
rule records defined at output O2 are
activated.
Flashing The configured VPN connection is
being established or aborted at output
O2.
The configured VPN connections are
being established or aborted at output
O2 or the firewall rule records defined at
output O2 are activated or deactivated.
WAN 1
1
Green On The LEDs are located in the sockets (10/100 and duplex LED)
Ethernet status. The LEDs indicate the status of the relevant port. As soon as the
device is connected to the relevant network, a continuous light indicates that there
is a connection to the network partner in the LAN, WAN or DMZ. When data pack-
ets are transmitted, the LED goes out briefly.
DMZ1 Green On
LAN 1–4 Green On
Bar graph LED 3 Top Off Off Off Green
LED 2 Middle Off Off Green Green
LED 1 Bottom Off Yellow Yellow Yellow
Signal strength -113 ... 111 dBm -109 ... 89 dBm -87 ... 67 dBm -65 ... 51 dBm
Network reception Very poor to none Sufficient Good Very good
SIM 1 Green On
Flashing
SIM card 1 active
No PIN or incorrect one entered
SIM 2 Green On
Flashing
SIM card 2 active
No PIN or incorrect one entered
1
only TC MGUARD RS4000 4G
Table 4-2 LEDs on the TC MGUARD RS4000 4G and TC MGUARD RS2000 4G [...]
