BLUEMARK LED
4-4
PHOENIX CONTACT 103933_en_01
4.3 Cleaning the printhead
The printhead is cleaned automatically with the first print job after the device is switched on.
As soon as the print image quality starts to deteriorate, individual nozzles fail or parts of a
line are missing, a cleaning cycle must be performed again.
4.3.1 Initiating printhead cleaning via the driver
• In the start menu, select "Settings... Printers and Faxes".
• Select the BLUEMARK LED printer and then click on "File... Properties".
• Switch to the "Maintenance" tab and click on the "Print Head Clean" icon.
4.3.2 Initiating printhead cleaning via the menu
• Press the f key to access the menu.
The printer switches to offline mode, i.e., printing is no longer possible.
• Select Maintenance via d. Confirm by pressing the
• key.
• Select Clean Print Head via d. Confirm by pressing the • key.
