BLUEMARK LED
5-8
PHOENIX CONTACT 103933_en_01
5.4 Creating a log file for the customer service
department
So that our customer service department can help you more quickly, you can generate a log
file and send it to the customer service department.
Switch on the printer.
If error messages or information are displayed, they must be removed or acknowledged
first. The printer can only create the log file when it is "ready".
Connect the printer to the PC via USB.
In the PC start menu, select "Settings... Printers and Faxes".
Select the BLUEMARK LED printer and then click on "File... Properties".
Figure 5-4 PHOENIX CONTACT BLUEMARK LED Properties: Maintenance
On the "Maintenance" tab, select the "Start status monitor" icon.
In the status monitor, select the "Info" tab.
Click on "Save log file".
Select a file name and a storage location. We recommend using the printer serial
number as the file name, e.g., "0824001001.log".
Data transmission takes around 1 minute. During transmission, a blue LED lights up on
the printer.
Send the file to the customer service department via e-mail.
If you no longer need the status monitor, you can remove it from the Windows task bar.
Right-click the status monitor symbol with the mouse and select „Exit“.
