Setting up and connecting the printer
103933_en_01 PHOENIX CONTACT 2-15
2.6 Initial printout (test sheet)
The BLUEMARK LED is now ready for printing.
Printing a test sheet A UC-TM 5 sheet (Order No. 0818108) is required for the test printout. A different type of
sheet can be used for the test printout. However, the samples may not be printed precisely
on the labels.
• Switch on the printer.
• Load a sheet (ideally UC-TM 5) in the input tray.
• In the start menu, select "Settings... Printers and Faxes".
• Select the BLUEMARK LED printer and then click on "File... Properties".
Figure 2-13 PHOENIX CONTACT BLUEMARK LED Properties: Maintenance
• On the "Maintenance" tab, select the "Testprint on UC-TM 5" icon.
