103933_en_01 PHOENIX CONTACT A-1
A Appendix
A 1 Technical data
General
Technology High-speed UV hardening
Print speed 10,000 markers/h, approximately (UC-TMF 4 with 2 characters/marker)
Print area
Horizontal
Vertical
0 mm ... 76 mm
0 mm ... 120 mm
Dimensions (W x H x D) 480 mm x 335 mm x 540 mm
Weight 24 kg, approximately
Power supply 100 V AC ... 240 V AC +6% and -10%
0.8 A ... 0.4 A
Power consumption 80 Watt (during printing)
Fuse 2 x F4.0 A/250 V
Locking mechanism Magnet (following unlocking via software)
Display size (L x W) 78 mm x 59 mm (320 pixels x 240 pixels)
Ambient temperature 5°C ... 35°C
Humidity 10% ... 80%
Media supply Automatic magazine for UniCard labeling sheets
Fluid system/range Contains 30 ml, up to 5000 sheets
(The range depends on the number of cleaning cycles and the ambient
temperature.)
Operating systems Windows XP, Windows 2000, Windows Vista, Windows 7
Interfaces
USB connection USB 2.0
Ethernet connection 10/100Base-TX Fast Ethernet
Bluetooth
Version Bluetooth 2.0, range of up to 100 m
Type EZURIO BISM ΙΙ, Intelligent Bluetooth Serial Module Version ΙΙ,
Type TRBLU23-00200, QPN reference number B02456
Class Class 1
Frequency 2.400 GHz ... 2.485 GHz
Transmission power 0 dBm ... 6 dBm
Receiver sensitivity Better than -90 dB
Transmitting and receiving antenna gain +2 dBi
Data transmission rate Up to 300 kbps
