BLUEMARK LED
5-6
PHOENIX CONTACT 103933_en_01
• When the jam has been removed, press e Cancel or • Continue. If Continue is
selected, the last print job is repeated.
Sheets are not being output correctly
Sheet Output Storage The Sheet Output Storage message means that an error occurred when ejecting the
sheets. Either the output tray is full or the sheets have become jammed.
• If the sheet is jammed further inside the device, switch the printer off and on.
After being switched on, an automatic evacuation process is carried out during device
initialization where any sheets trapped inside the device are ejected.
Opening the printer in the event of no voltage (emergency release) and removing
the sheet
If the above steps fail, because the sheet is jammed too tightly, the device can be opened
and the sheet removed manually:
• Switch off the printer.
Figure 5-2 Emergency release using the hexagonal screwdriver
• To unlock, insert the hexagonal screwdriver supplied with the printer in the slot on the
left-hand side of the printer.
• Press the pushbuttons on both sides of the printer and open the cover.
• Transport the sheets through manually.
WARNING: Risk of burns
During operation the UV Unit temperature is around 70°C. If in the event of an error you
want to open the printer via the emergency lock, you must wait a few minutes for the UV
Unit to cool down.
