Function Range
Resolution
Shunt
Resistance
1 Year
(23°C ± 5°C)
DCI
(DC
Current)
10.00000mA
10 nA 5.1Ω 0.050 + 0.020
100.0000mA
100 nA 5.1Ω
0.050 + 0.005
1.000000A 1 uA 0.1Ω
0.100 + 0.010
3.00000A 10 uA 0.1Ω
0.120 + 0.020
Function Range
Resolution
Test Current
1 Year
(23°C ± 5°C)
Resistance
4
100.0000 Ω
100 uΩ 1 mA
0.010 + 0.004
1.000000 KΩ
1 mΩ 1 mA
0.010 + 0.001
10.00000 KΩ
10 mΩ 100 uA
0.010 + 0.001
100.0000 KΩ
100 mΩ 10 uA
0.010 + 0.001
1.000000 MΩ
1 Ω 5 uA
0.010 + 0.001
10.00000 MΩ
10 Ω
500 nA
0.040 + 0.001
100.0000 MΩ
100 Ω 500 nA||10
MΩ
0.800 + 0.010
Diode Test
1.0000V 10 uV 1mA
0.010 + 0.020
Continuity
1000.00KΩ 10 mΩ 1mA
0.010 + 0.030
4
a. To use 2- / 4-Wire Ω Measurement , the Null math function must be
enabled.
b. Max. Lead Resistance: 10% of range per lead for 100Ω and 1KΩ
ranges; 1KΩ per lead for all other ranges.
c. Input protection: 1000 V at all ranges.
