Appendix
This appendix contains the performance specifications of the M3500A. It
covers the AC, DC, Resistance, Temperature, and Frequency/Period
characteristics under a variety of conditions. It also contains the general
characteristics and accuracy calculations for your convenience. A lot of
efforts are made to make sure these specifications serve your needs for
production, engineering and/or research purposes. All specification
applies to M3500A unless noted otherwise.
A. Specification List
DC Ch
aracteristics
Accuracy ± (% of reading + % of range)
1
Function
Range
2
Resolution
Input
Resistance
1 Year
(23°C ± 5°C)
DC Voltage
3
100.0000 mV
0.1 uV
> 10GΩ
0.0050 + 0.0035
1.000000 V 1.0 uV > 10GΩ 0.0040 + 0.0007
10.00000 V 10 uV > 10GΩ
0.0035 + 0.0005
100.0000 V 100 uV 10MΩ
0.0045 + 0.0006
1000.000 V 1 uV 10MΩ
0.0045 + 0.0010
1
The specifications are under the conditions, 6 ½ digits and 2-hour
warm-up.
2
Measurement over 20% at all ranges is allowable except the range
1000 VDC and 3 A.
3
a. Use continuous integrating A/D converter.
b. Input bias current: less than 30 pA at 25ºC.
c. Input protection: 1000 V at all ranges.
