Picotest M3500A - General Specifications

140
140140
140
B. General Specifications
item Limitation & description
Power Supply 100V/120V/220V/240V ± 10%
Power Line Frequency 50/60 Hz ± 10%
Power Consumption 25 VA peak (16 W average)
Operating Temperature
0 ℃ to 40 ℃
Operating Humidity
Maximum relative humidity 80% for temperature up to 31 ℃
Decreasing linearly to 50 percent relative humidity at 40 ℃
Storage Temperature - 40 ℃ to 70 ℃
Operating Altitude Up to 2000m
Dimensions for Rack
(WxHxD)
213.6 x 88.6 x 370.0 mm
Weight 3706 g
Safety
11
IEC61010-1:2001/EN61010-1:2001 (2
nd
Edition)
Over-Voltage Category CAT II, CAT I 1000V
UL61010-1:2004
Installation CAT II, Measurement CAT III at max. 1000V
Pollution Degree 2
EMC
EN61326-1:2006
EN61326-2-1:2006
EMI:
CISPR 11:1997+A1:1999+A2:2002 Class B
IEC61000-3-2:2000
IEC61000-3-3:1994+A1:2001
EMS:
IEC61000-4-2:1995+A1:1998+A2:2000
IEC61000-4-3:2002
IEC61000-4-4:2004
IEC61000-4-5:1995+A1:2000
IEC61000-4-6:1996+A1:2000
IEC61000-4-8:1993+A1:2000
IEC61000-4-11:1994+A1:2000
11
The LO jack is marked with 500Vpk against ground and SENSE HI to
LO is only marked with 200Vpk, in opposition to the label of 600V
CAT II and/or 1000V CAT I against ground and IEC 61010-1.
