【 Step 4 】
Remove the broken fuse from the selector as shown in Figure 2-9.
Figure 2-9
【 Step 5 】
Replace with the new fuse as shown in Figure 2-10.
Figure 2-10
【 Step 6 】
Insert the voltage setting selector back into the socket and close the cap
as shown in Figure 2-11.
Figure 2-11
