Picotest M3500A - Self-test

35
3535
35
⑥
⑥⑥
⑥ Connect test leads to your source signal and observe the reading
shown on the display. If the input signal is beyond the allowed range,
an overflow message “OVLD” will be displayed.
Figure 3-1
Figure 3-2
※ Note: The rear panel terminals can also be used via the same
procedures as the front panel terminals. (Refer to Figure 3.3)
