Front Panel≫ Rear Panel≫ Remote≫
1. COMPONENT VIDEO IN jacks: Input the AV component video signals with a
component video cable. (Compatible only with 480i or 576i resolution.)
2. Wireless antenna: Used for Wi-Fi connection or when using a BLUETOOTH
enabled device. Adjust their angles according to the connection status.
3. VIDEO IN jacks: Input the AV component video signals with an analog video
cable.
4.
AUDIO IN jacks: Input AV component audio signal with an analog audio cable.
5. HDMI IN jacks: Transmit video signals and audio signals with a HDMI cable
connected to an AV component.
6. SIGNAL GND terminal: The ground wire of the turntable is connected.
7. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI
cable connected to a monitor such as a TV or projector.
8. USB port: A USB storage device is connected so that music les stored in it
can be played. ( p103)
You can also supply power (5 V/0.5 A) to USB devices with a USB cable.
9. NETWORK port: Connect to the network with a LAN cable.
10.
DIGITAL AUDIO IN OPTICAL/COAXIAL jacks: Input TV or AV component
digital audio signals with a digital optical cable or digital coaxial cable.
11.
AC IN: The supplied power cord is connected.
12.
RS-232C port: Connect a home control system equipped with an RS-232C
port. For adopting a home control system, contact the specialized stores.
13.
ANTENNA AM LOOP/FM UNBAL 75 Ω terminal: The supplied antennas are
connected.
14.
IR IN/OUT port: Connect a remote control receiver unit. ( p90)
15.
12V TRIGGER OUT A/B jack: Connect a device equipped with a 12V trigger
input jack to enable power link operation between the device and this unit.
( p91)
16.
ZONE 2 PRE/LINE OUT jacks: Output audio signals with an analog audio
cable connected to a pre-main amplier or a power amplier in a separate
room (ZONE 2).
ZONE B LINE OUT jacks: Connect to a pre-main amplier with an analog
audio cable, and simultaneously output audio of the same source as that of
the speakers (ZONE A) connected to this unit.
17.
ZONE 3 PRE/LINE OUT jacks: Output audio signals with an analog audio
cable connected to a pre-main amplier or a power amplier in a separate
room (ZONE 3).
18.
SPEAKERS terminals: Connect speakers with speaker cables. (North
American models support banana plugs. Use a plug 4 mm in diameter. Y plug
connection is not supported.)
19.
SUBWOOFER PRE OUT jack: Connect a powered subwoofer with a
subwoofer cable. Up to two powered subwoofers can be connected. You can
set the volume levels of the 2 powered subwoofers to different levels.
( p162)
20.
PRE OUT jacks: Connect a power amplier. ( p74)
21.
VOLTAGE SELECTOR (multi-voltage models): Use a medium-sized
screwdriver to switch the voltage to the one appropriate for your region. Before
changing the voltage, rst disconnect the power cord.
To Next Page
