Planet GS-5220-16S8C User Manual

User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Object Description
 Port
The switch port number of the logical STP port.
 CIST Role
The current STP port role of the ICST port. The port role can be one of the
following values:
■ AlternatePort
■ BackupPort
■ RootPort
■ DesignatedPort
■ Disable
 CIST State
The current STP port state of the CIST port . The port state can be one of the
following values:
■ Disabled
■ Learning
■ Forwarding
 Uptime
The time since the bridge port was last initialized.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds
4.7.9 Port Statistics
This Page displays the STP port statistics counters for port physical ports in the currently selected switch.
The STP Port Statistics screen in Figure 4-7-12 appears.
Figure 4-7-12: STP Statistics Page Screenshot
The Page includes the following fields:
Object Description
 Port
The switch port number of the logical RSTP port.
149
