becomes a member of the multicast group by issuing IGMP/MLD messages.
Be Caution: MVR source ports are not recommended to be overlapped with
management VLAN ports.
Select the port role by clicking the Role symbol to switch the setting.
I indicates Inactive; S indicates Source; R indicates Receiver
The default Role is Inactive.
 Immediate Leave
Enable the fast leave on the port.
Buttons
: Click to add new MVR VLAN. Specify the VID and configure the new entry. Click "Save"
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.17 MVR Status
This Page provides MVR status. The MVR Status screen in Figure 4-8-20 appears.
Figure 4-8-20: MVR Status Page Screenshot
The Page includes the following fields:
Object Description
 VLAN ID
The Multicast VLAN ID.
 IGMP/MLD Queries
Received
The number of Received Queries for IGMP and MLD, respectively.
 IGMP/MLD Queries
Transmitted
The number of Transmitted Queries for IGMP and MLD, respectively.
 IGMPv1 Joins
Received
The number of Received IGMPv1 Joins.
 IGMPv2/MLDv1
Reports Received
The number of Received IGMPv2 Joins and MLDv1 Reports, respectively.
 IGMPv3/MLDv2
Reports Received
The number of Received IGMPv1 Joins and MLDv2 Reports, respectively.
177
