User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
The Page includes the following fields:
Object Description
 Port
The logical port for the settings.
 Filtering Profile
Select the IPMC Profile as the filtering condition for the specific port. Summary
about the desi
gnated profile will be shown by clicking the view button
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.7 IGMP Snooping Status
This Page provides IGMP Snooping status. The IGMP Snooping Status screen in Figure 4-8-10 appears.
Figure 4-8-10: IGMP Snooping Status Page Screenshot
The Page includes the following fields:
162
