User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
4.12.14 ARP Inspection Static Table
This Page provides Static ARP Inspection Table. The Static ARP Inspection Table screen in Figure 4-12-14 appears.
Figure 4-12-14: Static ARP Inspection Table Screen Page Screenshot
The Page includes the following fields:
Object Description
 Delete
Check to delete the entry. It will be deleted during the next save.
 Port
The logical port for the settings.
 VLAN ID
The VLAN ID for the settings.
 MAC Address
Allowed Source MAC address in ARP request packets.
 IP Address
Allowed Source IP address in ARP request packets.
Buttons
: Click to add a new entry to the Static ARP Inspection table.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.15 Dynamic ARP Inspection Table
Entries in the Dynamic ARP Inspection Table are shown on this Page. The Dynamic ARP Inspection Table contains up to 1024
entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address. The Dynamic ARP
Inspection Table screen in Figure 4-12-15 appears.
288
