User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
string length is 1 to 32, and the allowed content is the ASCII characters from 33
to 126.
 View Type
Indicates the view type that this entry should belong to. Possible view type are:
 included: An optional flag to indicate that this view subtree should be
included.
 excluded: An optional flag to indicate that this view subtree should be
excluded.
In general, if a view entry's view type is 'excluded', it should be exist another view
entry which view type is 'included' and it's OID subtree overstep the 'excluded'
view entry.
 OID Subtree
The OID defining the root of the subtree to add to the named view. The allowed
OID length is 1 to 128. The allowed string content is digital number or asterisk(*).
Buttons
: Click to add a new view entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.3.5.5 SNMPv3 Access
Configure SNMPv3 accesses table on this Page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access screen in Figure 4-3-8 appears.
Figure 4-3-8: SNMPv3 Accesses Configuration Page Screenshot
The Page includes the following fields:
Object Description
 Delete
Check to delete the entry. It will be deleted during the next save.
 Group Name
A string identifying the group name that this entry should belong to. The allowed
string length is 1 to 32, and the allowed content is the ASCII characters from 33
to 126.
82
