User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
4.12.4 HTTPs
Configure HTTPS on this Page. The HTTPS Configuration screen in Figure 4-12-4 appears.
Figure 4-12-4: HTTPS Configuration Screen Page Screenshot
The Page includes the following fields:
Object Description
Mode
Indicates the HTTPS mode operation. When the current connection is HTTPS, to
apply HTTPS disabled mode operation will automatically redirect web browser to
an HTTP connection. Possible modes are:
Enabled: Enable HTTPS mode operation.
Disabled: Disable HTTPS mode operation.
Automatic Redirect
Indicates the HTTPS redirect mode operation. It only significant if HTTPS mode
"Enabled" is selected. Automatically redirects web browser to an HTTPS
connection when both HTTPS mode and Automatic Redirect are enabled or
redirects web browser to an HTTP connection when both are disabled. Possible
modes are:
Enabled: Enable HTTPS redirect mode operation.
Disabled: Disable HTTPS redirect mode operation.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.5 SSH
Configure SSH on this Page. This Page shows the Port Security status. Port Security is a module with no direct configuration.
Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port,
the port is set-up for software-based learning. In this mode, frames from unknown MAC addresses are passed on to the port
security module, which in turn asks all user modules whether to allow this new MAC address to forward or block it. For a MAC
address to be set in the forwarding state, all enabled user modules must unanimously agree on allowing the MAC address to
274
