4.9.5 Port Shaping
This Page provides an overview of QoS Egress Port Shapers for all switch ports. The Port Shapping screen in Figure 4-9-4
appears.
Figure 4-9-4: QoS Egress Port Shapers Page Screenshot
The Page includes the following fields:
Object Description
The logical p
ort for the settings contained in the same row.
Click on the port number in order to configure the shapers.
For more detail, please refer to chapter 4.9.5.1.
Port
Show
s "disabled" or actual queue shaper rate - e.g. "800 Mbps".
Q0 ~Q7
Port
Shows "disabled" or actual port shaper rate - e.g. "800 Mbps".
