User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Figure 4-9-15: Storm Control Configuration Page Screenshot
The Page includes the following fields:
Object Description
The port number for
which the configuration below applies.
 Port
Controls
whether the storm control is enabled on this switch port.
 Enable
Controls the ra
te for the storm control. The default value is 500. This value is
restricted to 100-1000000 when the "Unit" is "kbps" or "fps", and it is restricted to
1-13200 when the "Unit" is "Mbps" or "kfps”.
 Rate
Controls the un
it of measure for the storm control rate as kbps, Mbps, fps or
kfps . The default value is "kbps".
 Unit
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
201
