User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
frames.
■ ARP: The ACE will match ARP/RARP frames.
■ IPv4: The ACE will match all IPv4 frames.
■ IPv4/ICMP: The ACE will match IPv4 frames with ICMP protocol.
■ IPv4/UDP: The ACE will match IPv4 frames with UDP protocol.
■ IPv4/TCP: The ACE will match IPv4 frames with TCP protocol.
■ IPv4/Other: The ACE will match IPv4 frames, which are not
ICMP/UDP/TCP.
■ IPv6: The ACE will match all IPv6 standard frames.
 Action
Indicates the forwarding action of the ACE.
■ Permit: Frames matching the ACE may be forwarded and learned.
■ Deny: Frames matching the ACE are dropped.
 Rate Limiter
Indicates the rate limiter number of the ACE. The allowed range is 1 to 16. When
Disabled is displayed, the rate limiter operation is disabled.
Indicates the p
ort redirect operation of the ACE. Frames matching the ACE are
redirected to the port number.
 Port Redirect
The allowed values are Disabled or a specific port number. When Disabled is
displayed, the port redirect operation is disabled.
 CPU
Forward packet that matched the specific ACE to CPU.
Fo
rward first packet that matched the specific ACE to CPU.
 CPU Once
The counter in
dicates the number of times the ACE was hit by a frame.
 Counter
Indicates the h
ardware status of the specific ACE. The specific ACE is not
applied to the hardware due to hardware limitations.
 Conflict
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page.
209
