User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
221
Specif
y the TCP "Push Function" (PSH) value for this ACE.
■ 0: TCP frames where the PSH field is set must not be able to match this
entry.
■ 1: TCP frames where the PSH field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
 TCP PSH
Specif
y the TCP "Acknowledgment field significant" (ACK) value for this ACE.
■ 0: TCP frames where the ACK field is set must not be able to match this
entry.
■ 1: TCP frames where the ACK field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
 TCP ACK
Specif
y the TCP "Urgent Pointer field significant" (URG) value for this ACE.
■ 0: TCP frames where the URG field is set must not be able to match this
entry.
■ 1: TCP frames where the URG field is set must be able to match this entry.
■ Any: Any value is allowed ("don't-care").
 TCP URG
 Ethernet Type Parameters
The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected.
Object Description
Specif
y the Ethernet type filter for this ACE.
■ Any: No EtherType filter is specified (EtherType filter status is
"don't-care").
■ Specific: If you want to filter a specific EtherType filter with this ACE,
you can enter a specific EtherType value. A field for entering a
EtherType value appears.
 Eth
erType Filter
When "S
pecific" is selected for the EtherType filter, you can enter a specific
EtherType value.
The allowed range is 0x600 to 0xFFFF but excluding 0x800(IPv4), 0x806(ARP)
and 0x86DD(IPv6). A frame that hits this ACE matches this EtherType value.
 Ethe
rnet Type Value
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Return to the previous Page.
