User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Request as well as a timeout.
This section contains information about the state of the server and the latest round-trip time.
 Other Info
Name
RFC4668 Name Description
- IP
address and UDP port for the authentication server
in question.
IP Address
State
- Shows the state of the server. It takes one of the
following values:
 Disabled: The selected server is disabled.
 Not Ready: The server is enabled, but IP
communication is not yet up and running.
 Ready: The server is enabled, IP communication
is up and running, and the RADIUS module is
ready to accept access attempts.
 Dead (X seconds left): Access attempts were
made to this server, but it did not reply within the
configured timeout. The server has temporarily
been disabled, but will get re-enabled when the
dead-time expires. The number of seconds left
before this occurs is displayed in parentheses.
This state is only reachable when more than one
server is enabled.
Round-Trip
Time
radiusAuthClient
ExtRoundTripTim
e
The time interval (measured in milliseconds) between
the most recent Access-Reply/Access-Challenge and
the Access-Request that matched it from the RADIUS
authentication server. The granularity of this
measurement is 100 ms. A value of 0 ms indicates
that there hasn't been round-trip communication with
the server yet.
RADIUS Accounting Statistics
The statistics map closely to those specified in RFC4670 - RADIUS Accounting Client MIB. Use the server select box to switch
between the backend servers to show details for.
Object Description
 Packet Counters
RADIUS accounting server packet counter. There are five receive and four transmit
counters.
257
