The Page includes the following fields:
Server Statistics
Object Description
 Transmit to Server
The packets number that relayed from client to server.
 Transmit Error
The packets number that errors sending packets to clients.
 Receive from Server
The packets number that received packets from server.
 Receive Missing Agent
Option
The packets number that received packets without agent information options.
 Receive Missing
Circuit ID
The packets number that received packets which the Circuit ID option was
missing.
 Receive Missing
Remote ID
The packets number that received packets which Remote ID option was missing.
 Receive Bad Circuit ID
The packets number that the Circuit ID option did not match known circuit ID.
Receive Bad Remote ID
The packets number that the Remote ID option did not match known Remote ID.
Client Statistics
Object Description
 Transmit to Client
The packets number that relayed packets from server to client.
 Transmit Error
The packets number that erroneously sent packets to servers.
 Receive from Client
The packets number that received packets from server.
 Receive Agent Option
The packets number that received packets with relay agent information option.
 Replace Agent Option
The packets number that replaced received packets with relay agent information
option.
 Keep Agent Option
The packets number that kept received packets with relay agent information
option.
 Drop Agent Option
The packets number that dropped received packets with relay agent information
option.
Buttons
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clears all statistics.
