Command Guide
-240-
<mac_addr> 48 bit MAC address: xx:xx:xx:xx:xx:xx
vlan VLAN keyword
<vlan_id> VLAN IDs 1-4095
interface Select an interface to configure
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
Default:
300
Usage Guide:
To configure Static MAC Address Table
Example:
To configure Static MAC Address Table as below table
Switch# configure terminal
Switch (config)# mac address-
table static 00:11:22:33:44:55 vlan 1 interface
GigabitEthernet 1/1
4.2.123 mep <Instance> ais
Command:
mep <Instance> ais [ fr1m | fr1s ] [ protect ]
mep Maintenance Entity Point
<Instance> The MEP instance number.
ais Alarm Indication Signal
fr1m Frame rate is 1 f/min.
fr1s Frame rate is 1 f/s.
protect The AIS can be used for protection. At the point of state change three AIS PDU is transmitted as fast as
possible.
Default:
None
Usage Guide:
To configure AIS of MEP
Example:
To configure AIS of MEP 1 as below table
