User’s Manual of IMG-2x00T Modbus Gateway Series
12
SFP module) Single mode
Distance 100m
2km to 120km,
vary on SFP
modules
IMG-2102T: 2km
IMG-2102TS:
30km
100m 100m
Cable Twisted-pair
 50 or
62.5/125μm
multi-mode
fiber cable
 9/125μm
single-mode
cable
 50/125μm or
62.5/125μm
multi-mode
fiber cable
 9/125μm
single-mode
cable
Twisted-pair Twisted-pair
Switch Architecture
- - Store-and-Forward-
Address Table - - 1K
ESD Protection 6KV
Surge Protection 2KV
Hardware
Installation DIN-rail kit and wall-mount ear
Enclosure IP 30 metal IP40 metal
Dimensions (W x D x H) 32 x 97 x 135 mm 56 x 87 x 135mm
Weight
392g 390g 387g 392g 625 g
LED Indicators
System: Link
TP/SFP Port: Link/ Active
Serial Port: Active
Power Requirements
9~48V DC / 24V AC, redundant power with reverse
polarity protection
12~48V DC, redundant power with
polarity reverse protection function
Power Consumption
Full Loading
9VDC: 0.35A
(3.15 watts)
12VDC: 0.28A
(3.36 watts)
24VDC: 0.12A
(3 watts)
48VDC: 0.08A
(3.84 watts)
Full Loading
9VDC: 0.44A
(3.96 watts)
12VDC: 0.33A (4
watts)
24VDC: 0.17A
(4.08 watts)
48VDC: 0.1A (4.8
watts)
 IMG-2102:
Full Loading
12VDC: 0.42A
(5 watts)
24VDC: 0.22A
(5.3 watts)
48VDC: 0.3A
(6 watts)
 IMG-2102TS:
Full Loading
12VDC: 0.43A
(5.1 watts)
24VDC: 0.23A
(5.5 watts)
48VDC: 0.3A
(6 watts)
Full Loading
12VDC: 0.326A
(3.8 watts)
24VDC: 0.176A
(4.2 watts)
48VDC: 0.114A
(5.4 watts)
Full Loading
12VDC: 0.419A
(5.1 watts)
24VDC: 0.227A
(5.4 watts)
48VDC: 0.136A
(6.5 watts)
Connector
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
DI and DO N/A 2 digital inputs:
