User’s Manual of IMG-2x00T Modbus Gateway Series
13
Level 0:
-24V~2.1V
(±0.1V)
Level 1:
2.1V~24V
(±0.1V)
Input Load to
24V DC, 10mA
max.
2 digital outputs:
Open collector to
24V DC, 100mA
max.
Alarm
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
Management
Management Interfaces
Web management
Telnet Console management
Windows-based VCOM Utility management
SNMPv1, v2c / SNMP Trap
UNI-NMS monitoring
PLANET Smart Discovery Utility
IP Version IPv4
Operation Mode
RTU Master
RTU Slave
ASCII Master
ASCII Slave
Virtual COM Utility
Platform Supports
Windows-based Only:
Windows XP
Windows Server 2003
Windows 7
Windows Server 2008
Windows 8 (Must install the latest version of WinPcap)
Windows Server 2012 (Must install the latest version of WinPcap)
Windows 10
Alert System log / SNMP Trap Built-in buzzer and RTC
Time NTP
Security Allows maximum 4 accessible IP address hosts/ranges
SNMP
RFC1213 MIB-II
RFC1317 RS232-like MIB
