User Manual of WDRT-1800AX
-49-
5.1.18 Virtual server
After using the router, Internet users cannot access the hosts in the LAN, so they cannot access Web, FTP, Mail
and other servers built on the intranet. The virtual server function can realize the mapping of the server of the
intranet to the Internet, so as to realize the opening of the server to the outside world.
Requirements: A small enterprise needs to open the file server and web server to the Internet through a router,
and the external port of the web server is 8080.
The configuration information is as follows:
WAN IP 10.11.104.11
Web Services
IP 192.168.1.10
Port 80
FTP Services
IP 192.168.1.11
Port 21
Users on the Internet can enter http:// WAN IP:External port (in this example: http:// 10.11.104.11:8080) to visit
your personal website.
Figure 5-32 Virtual server
