User Manual of WDRT-1800AX
-23-
Starting Setup in the Web UI
It is easy to configure and manage the WDRT-1800AX with the web browser.
Step 1. To access the configuration utility, open a web-browser and enter the default IP address
http://192.168.1.1 in the web address field of the browser.
Figure 4-9 Login the Router
After a moment, a login window will appear. Enter admin for the User Name and Password, both in lower case
letters. Then click the Log In button or press the Enter key.
Figure 4-10 Login Window
Default IP Address: 192.168.1.1
Default Password: admin
If the above screen does not pop up, it may mean that your web-
browser has been set to a
proxy. Go to Tools menu>Internet Options>Connections>LAN Settings in the screen that
appears, cancel the Using Proxy checkbox, and click OK to finish it.
