Planmeca ProOne - Double Lateral-PA and 3 Angles Lateral TMJ Programs

9 CONTROL PANEL
22 Planmeca ProOne User’s Manual
Double lateral-PA:
Lateral and posteroanterior TMJ exposures of open or
closed temporomandibular joints.
The imaging angle for the lateral exposure is adjustable
(factory default angle: 17°). The imaging angle for the
posteroanterior exposure is 60° and it is not adjustable.
3 angles lateral:
Three lateral multi-angle left-hand or right-hand side TMJ
exposures.
The imaging angle for image no. 2 is adjustable (three
imaging angles: factory default angle 17° ±7°). The
selected imaging angle is in image no. 2
Accept the selection and return to the main display by
touching the green check mark button in the bottom right
corner of the display.
1 cm
Double lateral-PA
1.
2. 3.4.
1 cm
1 2 3
3 angles lateral, left
First exposure = Selected angle - 7°
Second exposure = Angle selected by user
Third exposure = Selected angle + 7°
(factory default angle: 17°)
1.
2.
3.
