6 MAIN PARTS
8 Planmeca ProOne User’s Manual
6 MAIN PARTS
6.1 General view of X-ray system
1 X-ray unit
2Patient area
3 PC with Planmeca Romexis program
(outside patient area)
ProOne_013_2
2 m
79 in.
1
3
Ethernet
2
