10 MAIN PARTS
30 Planmeca ProScanner User’s & installation manual
Display symbols
Imaging plate (size)
NOIP (no imaging plate on the tray),
Size0, Size1, Size2, Size3, Size4c
Resolution
Temporarily toggles when it is touched.
Permanent changes can be made at the
Settings menu.
HD (High resolution)
SD (Standard resolution)
Connection status
No connection
Network connection
USB connection
Sleep button
See section 10.2.3 “Sleep mode” on page 31.
Settings button
See section 10.2.5 "Settings" on page 32.
