9.14
BRAKES
FRONT CALIPER
Removal
1. Loosen and remove brake line to caliper. Place a container
under caliper to catch fluid draining from brake line.
2. Push upper pad retainer pin inward and slip brake pads past
edge. Loosen pad adjuster.
3. Remove mounting bracket, pin assembly and dust boot.
4. Remove piston, dust seals and piston seals.
5. Clean the caliper body, piston, and retaining bracket with
brake cleaner or alcohol.
NOTE: Be sure to clean seal grooves in caliper
body.
CAUTION
Use care when supporting vehicle so that it does not
tip or fall. Severe injury may occur.
Clean Components
To Next Page
