10.9
ELECTRICAL
10
Speedometer Installation
1. Spray a soap and water mixture onto the outer surface area
of the instrument cluster. This will help the instrument
cluster slide into the pod assembly more easily.
2. Be sure the rubber grommet inside the pod is fully installed
and that the indexing key is in the headlight pod keyway.
3. Hold the pod assembly securely and insert the instrument
cluster into the pod assembly. Twist the instrument cluster
gently in a clockwise motion to properly seat the instrument
cluster into the pod assembly. Apply pressure on the bezel
while pressing down on the instrument cluster.
NOTE: Do not allow alcohol or petroleum products
to come in contact with the instrument cluster lens.
Align Index Pts.
