9.21
BRAKES
9
X2 REAR CALIPER
Removal
1. Clean caliper area before removal.
2. Place a container below the caliper to catch brake fluid that
will drain from the brake line. Remove brake line from
caliper
3. Remove the two caliper mounting bolts and the caliper.
4. Loosen the adjuster screw and remove the brake pads.
5. Remove mounting bracket, pin assembly and dust boot.
6. Remove piston, dust seals and piston seals.
7. Clean the caliper body, piston, and retaining bracket with
brake cleaner or alcohol.
NOTE: Be sure to clean seal grooves in caliper
body.
CAUTION
Use care when supporting vehicle so that it does not
tip or fall. Severe injury may occur.
Clean Components
