Polaris A09BG50AA User Manual

ELECTRICAL
10.17
NO REVERSE SPEED LIMIT (4X4)
SET P ARKING BRAKE
GEARCASE=REVERSE
REVERSE LAMP ON?
YES
NO
MEASURE DC VOLTS
GRY/OR WIRE TO
GROUND TO LR
MODULE
12 VOLTS DC?
FIND WHY
1. FAULTY BA TTERY
2. FAULTY CIRCUITY BREAKER
3. FAULTY IGNITION KEY SWITCH
4. FAULTY OFF-RUN SWITCH
4. FAULTY SHIFTER SWITCH?
5. WIRING/CONNECTIONS?
FIND WHY
1. FAULTY OVERRIDE SWITCH?
2. WIRING/CONNECTIONS?
NO
YES
MEASURE DC VOLTS
Y/R WIRE TO
GROUND TO LR
MODULE WITH EN-
GINE RUNNING AT
IDLE RPM
YES
3-- 9 VOLTS AC?
FIND WHY
1. WIRING/CONNECTIONS?
2. FAULTY CDI?
NO
DISCONNECT BLK WIRE
AT LR MODULE AND
GROUND HARNESS
SIDE TO CHASSIS
ENGINE STOP?
FIND WHY
1. FAULTY RECTIFIER/REGULATOR?
2. FAULTY CHARGING SYSTEM?
3. WIRING/CONNECTIONS?
NO
YES
REPLACE LR
MODULE
REVERSE SPEED LIMIT MODULE SC RAMBLER 500 4X4
THIS TEST REQUIRES A
“KNOWN GOOD” REVERSE
INDICATOR LAMP
KEY SWITCH=ON
OFF-RUN SWITCH=RUN
