ELECTRICAL
10.18
NO AWD (4X4)
IGNITION=ON
OFF-RUN SW.=RUN
GEARCASE=FORWARD
AWD LAMP ON?
FIND WHY
NO
1. FAULTY BA TTERY
2. FAULTY CIRCUIT BREAKER
3. FAULTY IGNITION SWITCH
4. FAULTY OFF-RUN SWITCH
5. FAULTY WHEEL COIL?
6. WIRING/CONNECTIONS?
7. MECHANICAL AWD FAULT?
YES
MEASURE DC VOLTS
BRN/WHT WIRE TO
GROUND AT LR
MODULE.
12 VOLTS DC?
FIND WHY
NO 1. FAULTY WHEEL COIL?
2. WIRING/CONNECTIONS?
3. MECHANICAL AWD FAULT?
YES
MEASURE DC VOLTS
GRY/OR WIRE TO
GROUND AT LR
MODULE.
0 VOLTS DC?
FIND WHY
NO 1. FAULTY OVERRIDE SWITCH?
2. FAULTY WIRING/CONNECTIONS?
YES
CONTINUE ON NEXT PAGE
REVERSE SPEED LIMIT MODULE SC RAMBLER 500 4X4
