Table 2-2 G7500 System Port Descriptions
Ref. Number Port Description
1 3.5 mm audio line out
2 3.5 mm audio line in
3 Security lock
4 Mini-DIN/RS-232 serial port
NOTE: The serial port is occasionally used by third party control system devices for automation.
5 USB-A ports
6 USB-C port
7 HDCI input for Polycom cameras
8 HDMI input for sharing content (for example, from a laptop)
9 HDMI output for the primary monitor
10 HDMI output for the secondary monitor
11 LAN connection for the system
12 Link-local network (LLN) connections for IP-based peripheral devices
13 Power cord port
Poly Studio X70 Hardware
Table 2-3
Ref. Number Feature Description
1 Screen Protective screen that covers the front
of the system
Poly Studio X70 Hardware 7
