Poly Studio X50 Administrator's Guide

Table 2-16 Studio X50 and Studio X30 LED Indicators and Status (continued)
Indicator Position Status
Solid red Four in the middle Muted camera
Muted microphone LEDs take
precedence over camera mute LEDs
Pulsing amber
All Firmware update in progress
Blinking red All Error preventing normal operation
Blinking amber Twelve alternating In a POST sequence, at least one test
results in a warning error. The system
continues to blink amber but initializes
after the sequence is complete if no
severe errors occur.
Blinking red
Twelve alternating In a POST sequence, at least one test
results in a severe error. The system
continues to blink red and doesn’t start
up.
LED Status Indicators for the Studio E70 Camera
The camera provides LED indicators on the front and right side of the camera to help you understand
the camera’s behaviors when connected to a G7500, Studio X series system, or a Windows PC.
Table 2-17
Studio E70 Camera System LED Status Indicators
Color and Pattern Status
Pulsing white Boot initialization is in progress
Solid white (50% brightness) Powered on but disconnected from video system
Sleep mode
Solid white (100% brightness)
Powered on and connected to the video system
Solid green In a call or the camera is active
Pulsing amber Firmware update or factory reset in progress
LED Status Indicators for the Studio E70 Camera 19

Poly Studio X50 Specifications

General

Bluetooth	Bluetooth 5.0
Video Output	HDMI
Zoom	5x digital zoom
Aperture	f/2.0
Power	100-240V AC, 50/60 Hz
Video Resolution	4K Ultra HD (3840 x 2160)
Camera Field of View	120 degrees
Audio Pickup Range	Up to 25 feet
Connectivity	Wi-Fi, Bluetooth
Ports	1x HDMI output 1x HDMI input
Supported Platforms	Zoom, Microsoft Teams
Video Standards	H.264, H.265
Audio Standards	G.711, G.722, G.722.1, G.729A
Wireless Protocol	802.11a/b/g/n/ac
Audio Output	3.5 mm line out
Ethernet	Gigabit Ethernet
Display	External display required
Operating System	Android-based
Weight	2.2 kg
