4 Soft keys Enable you to select context sensitive keys that display along the bottom of
the screen.
5 Transfer key Transfers an active call to a contact.
6 Dialpad keys Enable you to enter numbers, letters, and special characters. You can also
use the dialpad keys to select menu items that have index numbers.
7 Messages key Enables you to access and manage instant and voice messages.
8 Hold key Holds an active call or resumes a held call.
9 Microphone Transmits audio to other phones.
10 Volume keys Adjust the volume of the handset, headset, speaker, and ringer.
11 Mute key Mutes local audio during calls and conferences. The key glows red when
activated.
12 Speakerphone
key
Enables you to place and receive calls using the speakerphone. The key
glows green when activated.
13 Headset key Enables you to place and receive calls through a headset. The key glows
green when an analog headset is activated, and blue when a USB or
Bluetooth headset is activated.
14 Navigation key/
Select key
Scrolls through information or options displayed on the phone's screen.
Selects a field of displayed data.
15 Home key Displays the Home screen from other screens, and displays the Lines and
Calls screen from the Home screen.
16 Line keys Enable you to select a phone line, view calls on a line, or quickly call a
favorite contact.
17 Screen Shows a 3.2-inch (8.3 cm) diagonal screen with a backlight that enables
you to view menus and data.
18 Message Waiting
Indicator
Flashes red to indicate when you have new messages.
VVX 400 Series Hardware
The following figure displays the hardware features on the VVX 400, 401, 410, and 411 business media
phones. The table lists each feature numbered in the figure.
Getting Started with a VVX Business Media Phone
Polycom, Inc. 14
